MF - Hydraulic Pumps And Filters
|
MF
Hydraulic Pumps And Filters
|
|
|
NOTE:
Parts shown are BARE-Co parts - original part numbers are shown
for reference only
|
Ref
|
Part
No.
|
Replaces
|
Description
|
Application
|
|
1
|
B119
|
184472M93
|
Hydraulic
Pump
|
MF35-MF65
|
|
2
|
B9032
|
1684582M92
|
Mk
II Pump
With 10 spline camshaft
(filter faces up)
|
MF135
up to serial no. 447440
MF148 up to serial no.
606024
MF165 up to serial no.136610
MF168 up to serial no.
256093
MF175 and MF178,
MF1080, 1085-ALL
MF185 up to serial no.
320846
MF188 up to serial no.
361108
|
3 |
|
1684583M92 |
Mk II Pump
With 21 spline camshaft
(filter faces up)
Very rare |
MF135 from serial no.439191 to 447440
MF148 from serial no.605134 to 606024
MF165 from serial no.130773 to 136610
MF168 from serial no.255118 to 256093
MF185 from serial no.317618 to 320846
MF188 from serial no.358839 to 361108 |
|
4
|
B9033
|
1683301M91
|
Mk
III Pump
21 spline camshaft
(filter faces down)
|
MF135,
148, 165, 168, 185, 188
from above serial numbers +
MF240, 250, 265, 275, 285, 290,
298
550, 565, 575, 590, 595, 675, 690
698, 699, 365, 375, 390, 398, 399
|
5 |
|
884906M92
521451M1
|
Filter for Mk II Pump and
late Mk I Pump
(faces up) |
MF135 up to serial no. 447440
MF148 up to serial no. 606024
MF165 up to serial no.136610
MF168 up to serial no. 256093
MF175 and MF178, MF1080, 1085-ALL
MF185 up to serial no. 320846
MF188 up to serial no. 361108 |
|
6
|
B1279
|
1687042M91
1870199M92
|
Filter for Mk III Pump
(filter faces down)
|
MF135, 148, 165, 168, 185, 188
from above serial numbers +
MF240, 250, 265, 275, 285, 290, 298
550, 565, 575, 590, 595, 675, 690
698, 699, 365, 375, 390, 398, 399 |
|
7
|
B103
|
1686765M91
1686766M91
|
Auxiliary
Hydraulic Pump
Latest 2 port pump with blank plug for spare port
|
|
MF135
from 102832
MF135 from 553002
|
[Vertical
Mount
Plate]
|
When
dual auxiliary hydraulic pump fitted.
NOT
Suitable for very early tractors with flat base pump mounting
plate. |
|
8
|
B104
|
886821M94
|
Single
Multipower Pump
|
All
models shown above when fitted with single multipower
pump
i.e. Auxiliary pump not fitted
|
|
9
|
B1224
|
3539858M91
|
Hydraulic
Pump
|
MF154,
254, 263, 264
(MF353 up to ser. no. P06076)
MF363
|
|
B1225
|
3539857M91
|
Hydraulic
Pump
|
MF174,
184, 194, 274, 284, 294
(MF373 up to ser. no. P06076)
MF393
|
|
B1224
|
3539858M91
|
Power
Steering Pump
|
MF254, 264, 274, 294, 363,
MF353 & 393 up to ser. no. P06076 |
|
10
|
CR9333
|
1810539M91
|
Oil
Cooler filter
|
(MF188
from 361109) MF265, 275
MF285, 290
|
|
11
|
B1634
|
3382280M1
|
Tandem
Hydraulic Pump
|
MF3060,
3065, 3070, 3080, 3085, 3090, 3095
3115, 3120, 3120T, 3125, 3140, 3150, 6110, 6120,
6130, 6140, 6150, 6160, 6170, 6180, 6190, 6235, 6245,
6255, 6260, 6265, 6270, 6280, 6290
|
|
12
|
|
3533911M91
3534941M91
|
Hydraulic
Pump - 4mm Keyway
|
MF373
from
ser. no. PO6077
MF393
from
ser. no. PO6077 |
|
