90 HP "T" Series Gearbox
90 HP "T" Series Gearbox
Part No. B8513 - 1:1.5 ratio increase
SPECIFICATIONS

A = 290mm (11.4")
B = 208mm (8.2")
C = 208mm (8.2")
HOUSING:
SHAFTS:
GEARS:
SEALS:

BEARINGS:
OIL:
WEIGHT:
INPUT/ OUTPUT SHAFT:
60-45-10 Nodular
UNS G51200
UNS G51200
Triple Lipped
Spring Loaded
Tapered Roller
EP-140, 38oz, 1.12L
100 lbs, 45kg
1 3/8" x 6 spline
Standard Rotation
SPARE PARTS
PART No.
DESCRIPTION
INPUT SEAL
OUTPUT SEAL
THROUGH SHAFT
INPUT GEAR
OUTPUT GEAR
INPUT SHAFT 1 3/8" x 6 Splines
