Steering Wheels by Size
Steering Wheels by Size
NOTE: Parts shown are BARE-Co parts - original part numbers are shown for reference only.
PART No.
OUTSIDE DIA.
CENTRE BORE DIMENSION
CENTRE CAP
B1708
450mm

Tapered Hole Ø 17.6mm —> Ø 20mm
with 5mm Keyway

NO
450mm
Tapered Hole Ø 17.6mm —> Ø 20mm
with 5mm Keyway
Early Ferguson / Ford type with Steel Rod Spokes
NO
B3832
430mm

Ø 7/8" Fine Spline Tapered
Fits JD Models:
1020, 1120, 2020, 2120, 3120, 1030
1130, 1630, 1830, 2030, 2130, 3130

(1640, 2040, 2040S, 2140 with Hydrostatic steering i.e. No steering drag link)
4000, (4020 from 201000), 4030, 4040
4230, 4240, 4430, 4440, 4640, 4630
4840, 8430, 8440, 8630, 8640

YES
B9009
450mm

Ø 7/8" 6 Spline Tapered

YES
B9010
430mm

Ø 1 1/4" 48 Spline Tapered

YES
B9011
450mm

Ø 3/4" 36 Spline Tapered

YES
430mm
Ø 11/16 " 48 Spline
YES
